Freeze Drying Plant Sublimator 50

Freeze Drying Plant Sublimator 50
2.4m² shelves, -50°C condenser, 25kg ice capacity
Drying chamber
Dimensions: B600 x H700 x T700mm
Volume: 295 Liter
Shelve dimensions: 500 x 600mm
Shelve configuration: 8+1, 55mm distance
Total shelve dimensions: 2.4m²
Shelve temperature: -40°C bis +60°C
Ice condenser
Dimensions: Ø400 x 600mm
Volume: 75Liter
Capacity: 20kg/24h, max 25kg
Temperature: <-50°C
Defrosting: Hotgas
Outer dimensions: W880 x H1920 x D1650mm, 1000kg, 400V/50Hz 16A
Control:

Mitsubishi FXN mit 7“ coloured-touchpanel, 20 free defineable drying programs 1 flexible temperature sensor, vacuumcontrol, 30m³/h 2-stage vacuumpump, Edwards Stainless steel door with gauge glass Aircooled cooling unit
