Laboratory Freeze Dryer
Sublimator 5
Zirbus
12 months
Zirbus Laboratory Freeze Drying Unit Sublimator 2-3-3 Ideal for Development of Process Engineering / Research / Small Productions, GMP conformity...Lab Freeze dryer, Pilot Freeze dryer
Pilot/Laboratory Freeze Drying Unit Sublimator 2-3-3
Freeze Drying Unit Sublimator 2-3-3
Two chamber system
vials closing and maniford version
Ideal for Development of Process Engineering / Research / Small Productions
Compact table top freeze dryer
Micro-processing control
Visible condenser
Cooling and heatable shelves made of stainless steel
Many variations for expansion
Outer dimensions: W 800 x H 650 x D 600 mm
Additional options:
maniford with 6 or 12 connections
Removable inner rack made of aluminium, with infra-red heating
Sealing system for vials
GMP conformity
N2-liquid cooling
Visualtization, Siemens operation system
Batch documentation systems
Glovebox connection
|
Drying Chamber |
Condenser for ice |
||
|
Dimensions |
W250xH350xD350mm |
Dimensions |
Ø220x450mm |
|
Volume |
30 litres |
Volume |
17 litres |
|
Size |
200×300 mm |
Capacity |
5kg/24h |
|
shelf |
3 shelfex / 85mm distance, |
Temperature |
<-50°C/<-80°C |
|
Max. size |
0.30 m² |
Defrosting |
elestrically |
|
Temp. |
-35°C/-60°C |
|
|
