Laboratory Freeze Dryer

Laboratory Freeze Dryer

(4 đánh giá)

Sublimator 5

Zirbus

12 months

Zirbus Laboratory Freeze Drying Unit Sublimator 2-3-3 Ideal for Development of Process Engineering / Research / Small Productions, GMP conformity...Lab Freeze dryer, Pilot Freeze dryer

Pilot/Laboratory Freeze Drying Unit Sublimator 2-3-3

Freeze Drying Unit Sublimator 2-3-3

Two chamber system

vials closing and maniford version

Ideal for Development of Process Engineering / Research / Small Productions

Compact table top freeze dryer

Micro-processing control

Visible condenser

Cooling and heatable shelves made of stainless steel

Many variations for expansion

Outer dimensions: W 800 x H 650 x D 600 mm

Additional options:

maniford with 6 or 12 connections

Removable inner rack made of aluminium, with infra-red heating

Sealing system for vials

GMP conformity

N2-liquid cooling

Visualtization, Siemens operation system

Batch documentation systems

Glovebox connection

Drying Chamber

Condenser for ice

Dimensions

W250xH350xD350mm

Dimensions

Ø220x450mm

Volume

30 litres

Volume

17 litres

Size
of shelves

200×300 mm

Capacity

5kg/24h

shelf
configuration

3 shelfex / 85mm distance,
4/60, 5/45

Temperature

<-50°C/<-80°C

Max. size
of shelf

0.30 m²

Defrosting

elestrically
or by steam

Temp.
of shelf

-35°C/-60°C
up to  +60°C
